ELECTRIC CHAIN HOIST EH-II (BABY) SERIES

Home ELECTRIC CHAIN HOIST EH-II (BABY) SERIES

Leading Wholesale Trader and Authorised Distributor of ELECTRIC CHAIN HOIST EH-II (BABY) SERIES

Features

  • Capacity of 0.5t to 2t and height of lift of up to 40 meters.
  • Grade 80 alloy steel load chain ensures
  • Tested for an Safe Working Load 25% overload condition
  • Rugged German design is proven over 50 yearsy
  • Aluminium alloy motor stator packet allows better heat dissipation
  • Load chain wheel supported by two ball bearings
  • Precision machine case with hardened steel alloy gears
  • Fully pocketed load chain wheel is made of spheroidal graphite cast and alloy steel
  • Unique chain guide to guard chain passage
  • Chain stripper to safeguard the chain travel path
  • Hazardous application variants are available

    • USPs

    • Comes with a powerful conical rotor motor brake for a moderate number of start-stops and braking action
    • Comes with a powerful conical rotor motor brake for a moderate number of start-stops and braking action
    • Higher factor safety ensures maximum utility in areas with undefined load size
    • Micro-limit switches for additional safety braking
    • Micro-limit switches for additional safety braking
    • Standard ergonomic pendent with emergency stop

      • BENEFITS

      • Precise settings of the conical rotor brake motor for optimized consumption and long-life of motor windings
      • Hoist with plug-and-play functionality
      • Longer chain life
      • Smooth, low-noise operation
      • Assured safety
      • Extended application capability

    Titan Chain Pulley Block

Request a Quote
(FAQs) – (FAQs) – EH-II (Baby) Electric Chain Hoist
What is the lifting capacity of the EH-II hoist?

The EH-II "Baby" Electric Chain Hoist is available in capacities of 0.5 ton, 1 ton, and 2 tons, designed for a wide range of material handling applications across industries.

How high can it lift?

The standard lift height is 3 meters, but it can be customized up to 40 meters upon request. Perfect for both compact spaces and tall lifting needs.


How fast does it lift?

The EH-II offers hoisting speeds from 2.4 to 9 meters per minute, depending on model and load capacity – providing the right balance between performance and precision.

What safety features are included?

Safety is built-in: Dual brake system: including electromagnetic and mechanical brakes
Limit switches: prevent over-travel
Overload protection
Emergency stop switch on the control pendant

Is it suitable for hazardous environments?

Yes. Flameproof versions are available for explosive or flammable environments, such as chemical plants, oil refineries, and food/pharma production.

What kind of warranty or support is offered?

The hoist comes with a 1-year standard warranty. Additional support and extended warranty options are available through Patni Associates and authorized service partners.
